pin360 Docs
Everything you need to pin 360° panoramas to floor plans and share professional inspection reports.
Getting Started#
pin360 lets engineering teams pin 360° panoramic photos directly onto PDF floor plans — so anyone can understand exactly where on site a photo was taken.
Quick Start (5 minutes)
- Sign up at pin360.vercel.app/signup
- Create a Project (e.g.
Tower Bridge Inspection) - Add a Building or structure within that project
- Upload a PDF floor plan
- Click anywhere on the plan to drop your first marker
- Attach a 360° photo to that marker
- Share the view with a client using the Share button
Floor Plans#
Supported formats
- PDF (all versions) — recommended
- Multi-page PDFs supported; choose the page to display
Upload limits
- Up to 50MB per PDF
- Pages are rendered at high resolution for accuracy
Tips
- Use the original engineering drawing PDF for best quality
- If your PDF is very large, compress it first (Adobe Acrobat, Smallpdf)
Markers#
Two types of markers are available on any floor plan:
Mark exactly where you stood to take a 360° panoramic photo. Click to open the immersive panorama viewer.
Log defects, issues, or points of interest. Colour-coded by severity:
- Critical — red
- High — orange
- Medium — yellow
- Low — green
360° Photos#
Compatible cameras
Any camera that produces equirectangular (2:1 ratio) JPEG images:
- Insta360 ONE X2, X3, RS
- Ricoh Theta series
- GoPro MAX
- iPhone/Android with Google Street View app
- Any 360° camera app that exports equirectangular JPEG
Uploading
Select a marker → click Attach 360° → choose your file. Images are processed in the background. The viewer will load as soon as processing is complete.
Viewing
Click any blue sphere marker to open the panoramic viewer.
- Drag to look around
- Scroll to zoom
- Full-screen mode available
Sharing#
Share Links
Generate a public link from the Share button in the floor plan toolbar. Recipients can view the floor plan and all markers without creating an account. Share links can be set to expire after a date.
Report Export
Click Export Report to open a print-optimised view of all markers. Use your browser's Print function (Cmd+P / Ctrl+P) and choose Save as PDF.
FAQ#
Do my clients need to create an account to view?
No. Share links work without any login — clients can view the floor plan and all markers immediately.
What cameras work for 360° photos?
Any camera producing equirectangular JPEG images (2:1 ratio). Insta360, Ricoh Theta, GoPro MAX, and most 360 camera apps all work.
Can I use regular (non-360°) photos?
Yes. Upload them as 2D photos on any marker — they'll appear in the marker's photo gallery.
Is my data secure?
Files are stored in Cloudflare R2 with data encrypted at rest and in transit. We don't access your files.
What file formats are supported for floor plans?
PDF only currently. DWG/DXF import is on the roadmap.
